DeutschManufacturing example · Adapter plate · Aluminium 5083 · 15. mm
Adapter plate made of Alu 5083, 15 mm thick
Two CNC-milled adapter plates made of Alu 5083 with central bore and four mounting arms. Precision holes and counterbores for assembly.
Upload STEP fileMilling video
Ein Frästeil aus CAD-Daten.
wird online kalkuliert.
Der Preis berücksichtigt Material und Stückzahl.
Danach folgt die CNC-Bearbeitung.
Zum Schluss wird entgratet und kontrolliert.
Features
Manufacturing example
Adapter plate made of Alu 5083, 15 mm thick. CNC-milled with central bore, four mounting arms, and counterbores. Suitable for mounting and connecting components. Precision manufacturing, smooth surface.
Similar CNC parts
2 pcs. at 37.92 € net Aluminum Adapter Plate from Alu 5083, 8 mm thick
Rectangular adapter plate made of Alu 5083, 8 mm thick, with multiple holes and chamfers for mounting purposes.
View details →
3 pcs. at 19.65 € net Adapter plate from Alu 7075 with holes and slots
Two CNC-milled adapter plates from Alu 7075 with holes, slots, and countersinks. Thickness 6 mm.
View details →
1 pcs. at 38.09 € net Alu 5083 Mounting Plate 10mm with Holes
CNC milled mounting plate made from 10mm Aluminium 5083 with various holes and complex contour milling.
View details →
